1.LK.0501 Air Compressor, Twin Cylinder

1) II15698,II15698000,II15698AT,II15698AT000,II37214,II37214AT,K000236,K000236000,K000236AT,K000236V,K000236X00,K000236X07,K000236X57,LP4930,LP4974,1628593,20429339,3987602,8112584,8113264,85000064, 1.LK.0501 Air Compressor, Twin Cylinder, MPT Main Part

2) II15698,II15698000,II15698AT,II15698AT000,II37214,II37214AT,K000236,K000236000,K000236AT,K000236V,K000236X00,K000236X07,K000236X57,LP4930,LP4974,1628593,20429339,3987602,8112584,8113264,85000064, 1.LK.0501 Air Compressor, Twin Cylinder, MPT Main Part

1.LK.0501

Air Compressor, Twin Cylinder

EAN Code : 8683443010311

KNORR-BREMSE

Repair Kit

10.LP.0036

Air Compressor, Piston

10.LP.0041

Air Compressor, Ring

10.LK.1608

Air Compressor, Bushing

10.LP.0031

Air Compressor, Piston & Ring

10.LK.1837

Air Compressor, Crankshaft Flange

10.LK.1415

Air Compressor, Connecting Rod

1.LP.0510

Air Compressor, Gasket Kit

1.LP.0508

Air Compressor, Repair Kit

1.LP.0502

Air Compressor, Cylinder Head

10.LK.1027

Air Compressor, Housing

10.LK.1221

Air Compressor, Crankshaft

1.LP.0504

Air Compressor, Cylinder Head

1.LP.0505

Air Compressor, Valve Plate

1.LP.0514

Air Compressor, Valve Kit

1.LP.0512

Air Compressor, Valve Kit

1.LP.0503

Air Compressor, Repair Kit

1.LP.0501

Air Compressor, Repair Kit

1.LP.0513

Air Compressor, Unloader Kit

10.LP.0425

Air Compressor, Cylinder Liner Set

10.LK.2217

Air Compressor, Connecting Rod & Piston

10.LP.0372

Air Compressor, Cylinder Liner

Technical Specifications

Cylinder Bore	Ø88.00
Stroke	50 mm
Swept Volume	608cm³
Air Inlet Port	Ø29
Air Outlet Port	M26x1,5
Number of Cylinders	2
Through Drive	OK
Air Unloader Port	M22x1,5
Water (W) or Air (A) Cooled	W
Water Inlet Port	M16x1,5
Water Outlet Port	M16x1,5
With ESS Feature	OK
Water Cooled Valve Plate	OK
Weight	22,2 KG

Vehicles Used In

Marka	Model	Motor
KNORR-BREMSE
VOLVO

Diğer Oemler

KNORR-BREMSE	II15698
KNORR-BREMSE	II15698000
KNORR-BREMSE	II15698AT
KNORR-BREMSE	II15698AT000
KNORR-BREMSE	II37214
KNORR-BREMSE	II37214AT
KNORR-BREMSE	K000236
KNORR-BREMSE	K000236000
KNORR-BREMSE	K000236AT
KNORR-BREMSE	K000236V
KNORR-BREMSE	K000236X00
KNORR-BREMSE	K000236X07
KNORR-BREMSE	K000236X57
KNORR-BREMSE	LP 4930
KNORR-BREMSE	LP 4974
KNORR-BREMSE	K000236ES
KNORR-BREMSE	LP4930
KNORR-BREMSE	LP4974
VOLVO	1628593
VOLVO	20429339
VOLVO	3987602
VOLVO	8112584
VOLVO	8113264
VOLVO	85000064

Twin Cylinder, Air Compressor with code 1.LK.0501 meets the needs of your KNORR-BREMSE (II15698, II15698000, II15698AT, II15698AT000, II37214, II37214AT, K000236, K000236000, K000236AT, K000236V, K000236X00, K000236X07, K000236X57, LP4930, LP4974), VOLVO (1628593, 20429339, 3987602, 8112584, 8113264, 85000064) vehicles with MPT Main Part quality! With our wide product range, competitive prices, and strong presence in international markets, we add value to the performance of your vehicles. Choose us for reliable and quality solutions!
