1.LK.1801 Air Compressor, Twin Cylinder | MPT Main Part

1.LK.1801 | Air Compressor, Twin Cylinder

1.LK.1801 | Air Compressor, Twin Cylinder

1) 20382345,20478151,20569928,20773343,20842990,21388369,85000360,85000487,85000614,4127040060,4127040067,4127040100,4127040107,4127040140,4127040147,4127040240,1523988,1523988A,1523988R, 1.LK.1801 Air Compressor, Twin Cylinder, MPT Main Part

2) 20382345,20478151,20569928,20773343,20842990,21388369,85000360,85000487,85000614,4127040060,4127040067,4127040100,4127040107,4127040140,4127040147,4127040240,1523988,1523988A,1523988R, 1.LK.1801 Air Compressor, Twin Cylinder, MPT Main Part

1.LK.1801

Air Compressor, Twin Cylinder

EAN Code : 8683443010953

VOLVO

20382345

20478151

20569928

20773343

20842990

21388369

85000360

85000487

85000614

WABCO

412 704 006 0

412 704 006 7

412 704 010 0

412 704 010 7

412 704 014 0

412 704 014 7

412 704 024 0

DAF

1523988

1523988A

1523988R

Repair Kit

10.LP.0006 - Air Compressor, Piston

10.LP.0006

Air Compressor, Piston

10.LP.0001 - Air Compressor, Piston & Ring

10.LP.0001

Air Compressor, Piston & Ring

10.LP.0011 - Air Compressor, Ring

10.LP.0011

Air Compressor, Ring

10.LK.1608 - Air Compressor, Bushing

10.LK.1608

Air Compressor, Bushing

10.LK.1406 - Air Compressor, Connecting Rod

10.LK.1406

Air Compressor, Connecting Rod

1.LP.1801 - Air Compressor, Repair Kit

1.LP.1801

Air Compressor, Repair Kit

1.LP.1810 - Air Compressor, Cooling Plate

1.LP.1810

Air Compressor, Cooling Plate

1.LP.1806 - Air Compressor, Valve Plate

1.LP.1806

Air Compressor, Valve Plate

10.LK.1242 - Air Compressor, Crankshaft

10.LK.1242

Air Compressor, Crankshaft

10.LK.1854 - Air Compressor, Crankshaft Flange

10.LK.1854

Air Compressor, Crankshaft Flange

1.LP.1807 - Air Compressor, Cylinder Head

1.LP.1807

Air Compressor, Cylinder Head

1.LP.1803 - Air Compressor, Gasket Kit

1.LP.1803

Air Compressor, Gasket Kit

1.LP.1811 - Air Compressor, Repair Kit

1.LP.1811

Air Compressor, Repair Kit

10.LK.1047 - Air Compressor, Housing

10.LK.1047

Air Compressor, Housing

1.LP.1802 - Air Compressor, Cylinder Head

1.LP.1802

Air Compressor, Cylinder Head

1.LP.1812 - Air Compressor, Repair Kit

1.LP.1812

Air Compressor, Repair Kit

10.LP.0416 - Air Compressor, Cylinder Liner Set

10.LP.0416

Air Compressor, Cylinder Liner Set

10.LK.2211 - Air Compressor, Connecting Rod & Piston

10.LK.2211

Air Compressor, Connecting Rod & Piston

10.LK.2110 - Air Compressor, Crankshaft Repair Kit

10.LK.2110

Air Compressor, Crankshaft Repair Kit

10.LP.0250 - Air Compressor, Cylinder Liner

10.LP.0250

Air Compressor, Cylinder Liner

Technical Specifications

Cylinder Bore	Ø85.00
Stroke	62 mm
Swept Volume	704cm³
Air Inlet Port	Ø35
Air Outlet Port	M26x1,5
Number of Cylinders	2
Through Drive	OK
Air Unloader Port	M16x1,5
Water (W) or Air (A) Cooled	W
Water Inlet Port	M16x1,5
Water Outlet Port	M16x1,5
With ESS Feature	OK
Water Cooled Valve Plate	OK
Weight	22,2 KG

Vehicles Used In

Brand	Model	Engine
DAF
RENAULT TRUCKS	Magnum	DXi12
VOLVO	B9L	D9B
VOLVO	B9R	D9B
VOLVO	B9TL	D9B
VOLVO	FE	D9B
VOLVO	FH12	D12C
VOLVO	FH12	D12D
VOLVO	FH16	D16C
VOLVO	FM10	D10A
VOLVO	FM12	D12C
VOLVO	FM12	D12D
VOLVO	FM9	D9A
VOLVO	FM9	D9B
VOLVO	FM9 FM 9/260
VOLVO	FM9 FM 9/300
VOLVO	FM9 FM 9/340
VOLVO	FM9 FM 9/380
VOLVO	NH12	D12C
VOLVO	TAD1140-1172VE	D9
VOLVO	VHD	D12
VOLVO	VNL	D12
WABCO

Other OEMs

DAF	1523988
DAF	1523988A
DAF	1523988R
VOLVO	20382345
VOLVO	20478151
VOLVO	20569928
VOLVO	20773343
VOLVO	20842990
VOLVO	21388369
VOLVO	85000360
VOLVO	85000487
VOLVO	85000614
WABCO	412 704 006 0
WABCO	412 704 006 7
WABCO	412 704 010 0
WABCO	412 704 010 7
WABCO	412 704 014 0
WABCO	412 704 014 7
WABCO	412 704 024 0
WABCO	412.704.000.0
WABCO	412.704.006.0
WABCO	412.704.006.7
WABCO	412.704.010.0
WABCO	412.704.010.7
WABCO	412.704.014.0
WABCO	412.704.014.7
WABCO	412.704.024.0
WABCO	4127040000
WABCO	4127040060
WABCO	4127040067
WABCO	4127040100
WABCO	4127040107
WABCO	4127040140
WABCO	4127040147
WABCO	4127040240

20382345 20478151 20569928 20773343 20842990 21388369 85000360 85000487 85000614 412 704 006 0 412 704 006 7 412 704 010 0 412 704 010 7 412 704 014 0 412 704 014 7 412 704 024 0 1523988 1523988A 1523988R 1523988 Air Compressor, Twin Cylinder 1523988A Air Compressor, Twin Cylinder 1523988R Air Compressor, Twin Cylinder 20382345 Air Compressor, Twin Cylinder 20478151 Air Compressor, Twin Cylinder 20569928 Air Compressor, Twin Cylinder 20773343 Air Compressor, Twin Cylinder 20842990 Air Compressor, Twin Cylinder 21388369 Air Compressor, Twin Cylinder 85000360 Air Compressor, Twin Cylinder 85000487 Air Compressor, Twin Cylinder 85000614 Air Compressor, Twin Cylinder 412 704 006 0 Air Compressor, Twin Cylinder 412 704 006 7 Air Compressor, Twin Cylinder 412 704 010 0 Air Compressor, Twin Cylinder 412 704 010 7 Air Compressor, Twin Cylinder 412 704 014 0 Air Compressor, Twin Cylinder 412 704 014 7 Air Compressor, Twin Cylinder 412 704 024 0 Air Compressor, Twin Cylinder

Twin Cylinder, Air Compressor (1.LK.1801) offering special solutions for your VOLVO (20382345, 20478151, 20569928, 20773343, 20842990, 21388369, 85000360, 85000487, 85000614), WABCO (4127040060, 4127040067, 4127040100, 4127040107, 4127040140, 4127040147, 4127040240), DAF (1523988, 1523988A, 1523988R) VOLVO FM9, FE, FH12, FH16, FM10, FM12, NH12, VHD, VNL, B9L, B9R, B9TL, TAD1140-1172VE, RENAULT TRUCKS Magnum vehicles is with you with MPT Main Part privilege! With our active presence in the global market and economic solutions, we support your vehicle's performance and guarantee business continuity.
