Name: 4.LK.3001 Air Compressor, Triple Cylinder Compressor
Brand: MPT Main Part
SKU: 4.LK.3001

Repair Kit

4.LP.3008

Air Compressor, Repair Kit

4.LP.3011

Air Compressor, Repair Kit

4.LP.3001

Air Compressor, Cylinder Head

4.LP.3002

Air Compressor, Cylinder Head

4.LP.3003

Air Compressor, Cylinder Head

4.LP.3004

Air Compressor, Valve Plate

4.LP.3005

Air Compressor, Cylinder Head

4.LP.3006

Air Compressor, Cylinder Head

4.LP.3007

Air Compressor, Valve Plate

4.LP.3012

Air Compressor, Repair Kit

4.LP.3013

Air Compressor, Repair Kit

10.LK.1341

Air Compressor, Housing

10.LK.1397

Air Compressor, Crankshaft

10.LK.1462

Air Compressor, Crankshaft

10.LK.1468

Air Compressor, Crankshaft

10.LK.1452

Air Compressor, Connecting Rod

10.LK.1550

Air Compressor, Gear

10.LK.2045

Air Compressor, Bearing

10.LK.2228

Air Compressor, Connecting Rod & Piston

10.LK.2113

Air Compressor, Crankshaft Repair Kit

Technical Specifications

Cylinder Bore	Ø85.00
Stroke	56/37 mm
Swept Volume	636/210 cm³
Air Inlet Port	Ø25
Air Outlet Port	M26x1,5
Number of Cylinders	3
Through Drive	OK
Air Unloader Port	M10x1,5
Water (W) or Air (A) Cooled	W
Water Inlet Port	M16x1,5
Water Outlet Port	M16x1,5
Water Cooled Valve Plate	OK

Vehicles Used In

Brand	Model	Engine
MERCEDES BENZ	CAPACITY CAPACITY	OM 457 HLA
MERCEDES BENZ	CITARO (O 530) Citaro G	OM 457 HLA
MERCEDES BENZ	CITARO (O 530) Citaro G	OM 457 LA
MERCEDES BENZ	CITARO (O 530) Citaro GN3	OM 457 HLA
MERCEDES BENZ	CITARO (O 530) Citaro GN3	OM 457 LA
MERCEDES BENZ	CITARO (O 530) Citaro LÜ	OM 457 HLA
MERCEDES BENZ	CITARO (O 530) Citaro LÜ	OM 457 LA
MERCEDES BENZ	CITARO (O 530) Citaro MUE	OM 457 HLA
MERCEDES BENZ	CITARO (O 530) Citaro MUE	OM 457 LA
MERCEDES BENZ	CITARO (O 530) Citaro N	OM 457 HLA
MERCEDES BENZ	CITARO (O 530) Citaro N	OM 457 LA
MERCEDES BENZ	CONECTO (O 345) CONECTO 12M
MERCEDES BENZ	CONECTO (O 345) CONECTO 12M	OM 457 LA
MERCEDES BENZ	CONECTO (O 345) CONECTO 18M	OM 447 HLA
MERCEDES BENZ	CONECTO (O 345) CONECTO 18M	OM 457 LA
SETRA	Series 400 MultiClass S 415 NF	OM 457 HLA
SETRA	Series 400 MultiClass S 415 UL	OM 457 HLA
SETRA	Series 400 MultiClass S 415 UL	OM 457 LA
SETRA	Series 400 MultiClass S 416 NF	OM 457 HLA
WABCO

Other OEMs

MERCEDES BENZ	457 130 38 15
MERCEDES BENZ	457 130 50 15
MERCEDES BENZ	457.130.38.15
MERCEDES BENZ	457.130.50.15
MERCEDES BENZ	4571303815
MERCEDES BENZ	4571305015
MERCEDES BENZ	A457 130 38 15
MERCEDES BENZ	A457 130 50 15
MERCEDES BENZ	A4571303815
MERCEDES BENZ	A4571305015
WABCO	912 510 300 0
WABCO	912 510 303 0
WABCO	912.510.300.0
WABCO	912.510.303.0
WABCO	9125103000
WABCO	9125103030

912 510 300 0 912 510 303 0 457 130 38 15 457 130 50 15 457 130 38 15 Air Compressor, Triple Cylinder Compressor 457 130 50 15 Air Compressor, Triple Cylinder Compressor 912 510 300 0 Air Compressor, Triple Cylinder Compressor 912 510 303 0 Air Compressor, Triple Cylinder Compressor

The ideal solution for WABCO (9125103000, 9125103030), MERCEDES BENZ (4571303815, 4571305015) MERCEDES BENZ CITARO (O 530), CONECTO (O 345), CAPACITY, SETRA Series 400 in the Triple Cylinder Compressor, Air Compressor category: 4.LK.3001 awaits you at MPT Main Part! With our superior service approach in the global market, economic price policy, and fast delivery advantage, we make a difference in the commercial vehicle sector.
