5.LK.1201 Air Compressor, Twin Cylinder

5.LK.1201 | Air Compressor, Twin Cylinder
5.LK.1201 | Air Compressor, Twin Cylinder
1) 9125180000,9125180010,9125180020,9125180030,9125180040,1674920,1681561,1687079,1696197,1696197R, 5.LK.1201 Air Compressor, Twin Cylinder, MPT Main Part
2) 9125180000,9125180010,9125180020,9125180030,9125180040,1674920,1681561,1687079,1696197,1696197R, 5.LK.1201 Air Compressor, Twin Cylinder, MPT Main Part

5.LK.1201

Air Compressor, Twin Cylinder

EAN Code : 8683443014814
WABCO
912 518 000 0
912 518 001 0
912 518 002 0
912 518 003 0
912 518 004 0
DAF
1674920
1681561
1687079
1696197
1696197R

Technical Specifications

Cylinder Bore Ø85.00
Stroke 62 / 21mm
Swept Volume 352 / 119 cm³
Air Inlet Port M33x2
Air Outlet Port M22x1,5
Number of Cylinders 2
Through Drive OK
Air Unloader Port M14x1,5
Water (W) or Air (A) Cooled W
Water Inlet Port M16x1,5
Water Outlet Port M16x1,5
With ESS Feature OK
Water Cooled Valve Plate OK
Weight 30,7 KG

Vehicles Used In

Marka Model Motor
DAF CF 85.360 EURO5
DAF CF 85.410 EURO5
DAF CF 85.460 EURO5
DAF CF 85.510 EURO5
DAF CF85
DAF XF 105.410 EURO5
DAF XF 105.460 EURO5
DAF XF 105.510 EURO5
DAF XF 410 EURO5
DAF XF 430 EURO5
DAF XF 460 EURO5
DAF XF 480 EURO5
DAF XF 510 EURO5
DAF XF 530 EURO5
DAF XF105
DAF
WABCO

Diğer Oemler

DAF 1674920
DAF 1681561
DAF 1687079
DAF 1696197
DAF 1696197R
WABCO 912 518 000 0
WABCO 912 518 001 0
WABCO 912 518 002 0
WABCO 912 518 003 0
WABCO 912 518 004 0
WABCO 912.518.000.0
WABCO 912.518.001.0
WABCO 912.518.002.0
WABCO 912.518.003.0
WABCO 912.518.004.0
WABCO 9125180000
WABCO 9125180010
WABCO 9125180020
WABCO 9125180030
WABCO 9125180040
912 518 000 0 912 518 001 0 912 518 002 0 912 518 003 0 912 518 004 0 1674920 1681561 1687079 1696197 1696197R 1674920 Air Compressor, Twin Cylinder 1681561 Air Compressor, Twin Cylinder 1687079 Air Compressor, Twin Cylinder 1696197 Air Compressor, Twin Cylinder 1696197R Air Compressor, Twin Cylinder 912 518 000 0 Air Compressor, Twin Cylinder 912 518 001 0 Air Compressor, Twin Cylinder 912 518 002 0 Air Compressor, Twin Cylinder 912 518 003 0 Air Compressor, Twin Cylinder 912 518 004 0 Air Compressor, Twin Cylinder
Increase the efficiency and reliability of your WABCO (9125180000, 9125180010, 9125180020, 9125180030, 9125180040), DAF (1674920, 1681561, 1687079, 1696197, 1696197R) DAF CF 85.360 EURO5, CF 85.410 EURO5, CF 85.460 EURO5, CF 85.510 EURO5, CF85, XF 105.410 EURO5, XF 105.460 EURO5, XF 105.510 EURO5, XF 410 EURO5, XF 430 EURO5, XF 460 EURO5, XF 480 EURO5, XF 510 EURO5, XF 530 EURO5, XF105, vehicles with 5.LK.1201 coded Twin Cylinder, Air Compressor offered by MPT Main Part! With our global trade network that expands worldwide, we support our customers' business processes by offering a wide range of products and economic solutions.
