1.LP.3601
OE cross reference
OE numbers: 3WABCO
Technical Specifications
14- Cylinder Diameter (mm)
- Ø85.00
- Stroke
- 56 mm
- Air Inlet Port
- Ø35
- Air Outlet Port
- M26x1,5
- Number of Cylinders
- 2
- Through Drive
- OK
- Air Unloader Port
- M16x1,5
- Water (W) or Air (A) Cooled
- W
- Water Inlet Port
- M16x1,5
- Water Outlet Port
- M16x1,5
- With ESS Feature
- OK
- Water Cooled Valve Plate
- OK
- Swept Volume
- 636cm³
- Exhaust Emission Standard
- EURO 6
Repair Kit
18
10.LP.0006
Ø85,00mm (STD), Air Compressor, Piston
10.LP.0001
Ø85,00mm (STD), Air Compressor, Piston & Ring
10.LP.0011
Air Compressor, Piston Ring
10.LK.1407
Air Compressor, Connecting Rod
10.LK.1617
Air Compressor, Bushing
10.LK.2212
Air Compressor, Connecting Rod & Piston
1.LP.1915
Air Compressor, Crankshaft Flange
1.LP.3607
Air Compressor, Cylinder Head
1.LP.3608
Air Compressor, Valve Plate
1.LP.3613
Air Compressor, Repair Kit
1.LP.3614
Air Compressor, Repair Kit
1.LP.3615
Air Compressor, Repair Kit
1.LP.3617
Air Compressor, Repair Kit
1.LP.3618
Air Compressor, Repair Kit
10.LK.1343
Air Compressor, Housing
10.LK.1463
Air Compressor, Crankshaft
10.LK.2044
Air Compressor, Bearing
Vehicles Used In
17
Other OEMs
Check the number for typos, try it without spaces or dots, or search by part name.
Tags
Description
Meet the MPT Main Part products in the With Clutch, Air Compressor category with 1.LK.3652 stock code, and elevate the performance and durability of your VOLVO (22209417, 22372994), WABCO (9125120320) VOLVO , FH (FH4/FH5), FH16, FM, FMX, VNL, B11R, B13R, TAD1350-1360VE, MACK Anthem, RENAULT TRUCKS C, K, T brand vehicles to the highest level! With our strong sales network spread across the globe, our wide product range, and budget-friendly competitive prices, you will find the most ideal parts for your vehicle fleet with us, thereby significantly increasing your business efficiency. Make a difference in the sector with MPT Main Part quality!
