22.BS.0131 4-circuit protection valve
22.BS.0131
4-circuit protection valve
EAN Code :KNORR-BREMSE
IVECO
Technical Specifications
| Port 1 | M22x1,5 |
| Port 21 | M16x1,5 |
| Port 22 | M16x1,5 |
| Port 23 | M16x1,5 |
| Port 24 | M16x1,5 |
| Operating Pressure | 12 BAR |
| Opening Pressure 21 | 6,9 BAR |
| Opening Pressure 22 | 6,9 BAR |
| Opening Pressure 23 | 6,9 BAR |
| Opening Pressure 24 | 7 BAR |
| Closing Pressure 21 | 4,5 BAR |
| Closing Pressure 22 | 4,5 BAR |
| Closing Pressure 23 | 4,5 BAR |
| Closing Pressure 24 | 4,5 BAR |
| Pressure | MAX 20 BAR |
Vehicles Used In
| Marka | Model | Motor |
|---|---|---|
| DAF | ||
| IVECO | ||
| KNORR-BREMSE | ||
| MAN |
81.52151-6093
81.52151-6096
81.52151-6097
1519373
1521199
AE 4613
97166254
1519373 4-circuit protection valve
1521199 4-circuit protection valve
97166254 4-circuit protection valve
AE 4613 4-circuit protection valve
81.52151-6093 4-circuit protection valve
81.52151-6096 4-circuit protection valve
81.52151-6097 4-circuit protection valve
Possessing the stock code 22.BS.0131, the 4-circuit protection valve category products from MPT Main Part are here to meet you, elevating the performance and durability of your MAN (81521516093, 81521516096, 81521516097), DAF (1519373, 1521199), KNORR-BREMSE (AE4613), IVECO (97166254) brand vehicles to the peak! Thanks to our strong sales network spreading across the world, our wide product range, and budget-friendly competitive prices, you will find the most ideal parts for your vehicle fleet with us, thereby significantly increasing your business efficiency. Make a difference with MPT Main Part quality!
