22.BS.0185
4-circuit protection valve
22.BS.0132 4-circuit protection valve
Compatible with KNORR-BREMSE, IVECO
- MPT code
- 22.BS.0132
- EAN Code
- 8683443078182
OE cross reference
OE numbers: 3KNORR-BREMSE
IVECO
Technical Specifications
15- Port 1
- M22x1,5
- Port 21
- M16x1,5
- Port 22
- M16x1,5
- Port 23
- M16x1,5
- Port 24
- M16x1,5
- Operating Pressure
- 13 BAR
- Opening Pressure 21
- 7,5 BAR
- Opening Pressure 22
- 7,5 BAR
- Opening Pressure 23
- 8 BAR
- Opening Pressure 24
- 8 BAR
- Closing Pressure 21
- 6,5 BAR
- Closing Pressure 22
- 6,5 BAR
- Closing Pressure 23
- 6,5 BAR
- Closing Pressure 24
- 6,5 BAR
- Pressure
- MAX 20 BAR
Repair Kit
3Products Used In
3Vehicles Used In
2
| Brand | Model | Engine |
|---|---|---|
| IVECO | ||
| KNORR-BREMSE |
Other OEMs
Check the number for typos, try it without spaces or dots, or search by part name.
Tags
Description
Experience the MPT Main Part difference with 22.BS.0132 coded 4-circuit protection valve products, maximize performance and durability in your KNORR-BREMSE (AE4646, K019909N00), IVECO (98400429) vehicles! With our global sales network, wide product range, and competitive price policy, we offer ideal solutions for your vehicles, increasing your business efficiency.
