22.BS.0185
4-circuit protection valve
22.BS.0133 4-circuit protection valve
Compatible with KNORR-BREMSE
- MPT code
- 22.BS.0133
- EAN Code
- 8683443078199
OE cross reference
OE numbers: 5KNORR-BREMSE
Technical Specifications
15- Port 1
- M22x1,5
- Port 21
- M16x1,5
- Port 22
- M16x1,5
- Port 23
- M16x1,5
- Port 24
- M16x1,5
- Operating Pressure
- 13 BAR
- Opening Pressure 21
- 6,3 BAR
- Opening Pressure 22
- 6,3 BAR
- Opening Pressure 23
- 5,8 BAR
- Opening Pressure 24
- 5,8 BAR
- Closing Pressure 21
- 4,8 BAR
- Closing Pressure 22
- 4,8 BAR
- Closing Pressure 23
- 4,8 BAR
- Closing Pressure 24
- 3,8 BAR
- Pressure
- MAX 20 BAR
Repair Kit
3Products Used In
3Vehicles Used In
1
| Brand | Model | Engine |
|---|---|---|
| KNORR-BREMSE |
Other OEMs
- KNORR-BREMSE AE 4603
- KNORR-BREMSE II36011
- KNORR-BREMSE II36011004
- KNORR-BREMSE II3601105T
- KNORR-BREMSE II36011N00
- KNORR-BREMSE AE4603
Check the number for typos, try it without spaces or dots, or search by part name.
Tags
Description
Specially developed 4-circuit protection valve (22.BS.0133) for KNORR-BREMSE (AE4603, II36011, II36011004, II3601105T, II36011N00) vehicles increases the efficiency of your vehicles with MPT Main Part! With our wide stock variety and fast shipping options, we guarantee customer satisfaction by offering the most suitable solutions for your commercial vehicles.
