22.BS.0136 4-circuit protection valve
Technical Specifications
| Port 1 | M22x1,5 |
| Port 21 | M16x1,5 |
| Port 22 | M16x1,5 |
| Port 23 | M16x1,5 |
| Port 24 | M16x1,5 |
| Operating Pressure | 12 BAR |
| Opening Pressure 21 | 8 BAR |
| Opening Pressure 22 | 8 BAR |
| Opening Pressure 23 | 8,3 BAR |
| Opening Pressure 24 | 8 BAR |
| Closing Pressure 21 | 5,5 BAR |
| Closing Pressure 22 | 5,5 BAR |
| Closing Pressure 23 | 5,5 BAR |
| Closing Pressure 24 | 5,5 BAR |
| Pressure | MAX 20 BAR |
Vehicles Used In
| Marka | Model | Motor |
|---|---|---|
| KNORR-BREMSE |
Diğer Oemler
4-circuit protection valve with number 22.BS.0136 adds power to the power of your KNORR-BREMSE (AE4615, II39140F, II39140FM1) vehicles with MPT Main Part! With our quality product variety and competitive price policy, we exceed our customers' expectations in the global market.
