22.BS.0143 4-circuit protection valve
Technical Specifications
| Port 1 | M22x1,5 |
| Port 21 | M16x1,5 |
| Port 22 | M16x1,5 |
| Port 23 | M16x1,5 |
| Port 24 | M16x1,5 |
| Operating Pressure | 13 BAR |
| Opening Pressure 21 | 7 BAR |
| Opening Pressure 22 | 7 BAR |
| Opening Pressure 23 | 7 BAR |
| Opening Pressure 24 | 7 BAR |
| Closing Pressure 21 | 5,5 BAR |
| Closing Pressure 22 | 5,5 BAR |
| Closing Pressure 23 | 5,5 BAR |
| Closing Pressure 24 | 5,5 BAR |
| Pressure | MAX 20 BAR |
Vehicles Used In
| Marka | Model | Motor |
|---|---|---|
| KNORR-BREMSE |
Diğer Oemler
Specially developed 4-circuit protection valve (22.BS.0143) for KNORR-BREMSE (AE4644, K019907N00) vehicles increases the efficiency of your vehicles with MPT Main Part! With our wide stock variety and fast shipping options, we guarantee customer satisfaction by offering the most suitable solutions for your commercial vehicles.
