22.BS.0185
4-circuit protection valve
22.BS.0145 4-circuit protection valve
Compatible with KNORR-BREMSE
- MPT code
- 22.BS.0145
- EAN Code
- 8683443078311
OE cross reference
OE numbers: 2Technical Specifications
15- Port 1
- M22x1,5
- Port 21
- M16x1,5
- Port 22
- M16x1,5
- Port 23
- M16x1,5
- Port 24
- M16x1,5
- Operating Pressure
- 12 BAR
- Opening Pressure 21
- 6,5 BAR
- Opening Pressure 22
- 6,5 BAR
- Opening Pressure 23
- 6,5 BAR
- Opening Pressure 24
- 6,5 BAR
- Closing Pressure 21
- 4,5 BAR
- Closing Pressure 22
- 4,5 BAR
- Closing Pressure 23
- 4,5 BAR
- Closing Pressure 24
- 4,5 BAR
- Pressure
- MAX 20 BAR
Repair Kit
3Products Used In
3Vehicles Used In
1
| Brand | Model | Engine |
|---|---|---|
| KNORR-BREMSE |
Other OEMs
Check the number for typos, try it without spaces or dots, or search by part name.
Tags
Description
Special 4-circuit protection valve (22.BS.0145) solutions for your KNORR-BREMSE (AE4648, K019911) vehicles are at your service worldwide with MPT Main Part privilege! With our customer-focused approach and economic prices, we meet the needs of your commercial vehicles on a global scale.
