4-Circuit Protection Valve

22.BS.0148 4-Circuit Protection Valve

Compatible with KNORR-BREMSE, RENAULT TRUCKS, IVECO

MPT code
22.BS.0148
EAN Code
8683443078335
WhatsApp

OE cross reference

OE numbers: 7

RENAULT TRUCKS

IVECO

Technical Specifications

15
Port 1
M22x1,5
Port 21
Ø9 mm
Port 22
Ø9 mm
Port 23
Ø9 mm
Port 24
Ø9 mm
Operating Pressure
12,5 BAR
Opening Pressure 21
7 BAR
Opening Pressure 22
7 BAR
Opening Pressure 23
7 BAR
Opening Pressure 24
7,3 BAR
Closing Pressure 21
4,5 BAR
Closing Pressure 22
4,5 BAR
Closing Pressure 23
4,5 BAR
Closing Pressure 24
4,5 BAR
Pressure
MAX 20 BAR

Repair Kit

3

Products Used In

3

Vehicles Used In

3
Brand Model Engine
IVECO
KNORR-BREMSE
RENAULT TRUCKS

Other OEMs

8

Tags

Description

The ideal solution for KNORR-BREMSE (AE4605, II36650, II36650R, K011255, K099797N00), RENAULT TRUCKS (5010422971), IVECO (5006143813) in the 4-Circuit Protection Valve category: 22.BS.0148 awaits you at MPT Main Part! With our superior service approach in the global market, economic price policy, and fast delivery advantage, we make a difference in the commercial vehicle sector.
