22.BS.0149

4-circuit protection valve

EAN Code : 8683443023618
VOLVO
20382309
20452151
20716313
20755195
21225479
WABCO
934 714 140 0
934 714 740 0
DAF
1528375

Technical Specifications

Port 1 M22x1,5
Port 12 M16x1,5
Port 21 M16x1,5
Port 22 M16x1,5
Port 11 M16x1,5
Port 23 M16x1,5
Port 24 M16x1,5
Opening Pressure 21 6,3 BAR
Opening Pressure 22 6,3 BAR
Opening Pressure 23 5,8 BAR
Opening Pressure 24 5,8 BAR
Closing Pressure 23 4 BAR
Closing Pressure 24 4,5 BAR
Pressure MAX 13 BAR
Increase the efficiency and reliability of your VOLVO (20382309, 20452151, 20716313, 20755195, 21225479), WABCO (9347141400, 9347147400), DAF (1528375) MACK Granite, Pinnacle, RENAULT TRUCKS Kerax, Magnum, Premium, VOLVO FH12, FH13, FH16, FM10, FM11, FM12, FM13, FMX, NH12, VHD, VNL, B11R, B13R, TAD1341-1345VE vehicles with 22.BS.0149 coded 4-circuit protection valve offered by MPT Main Part! With our global trade network that expands worldwide, we support our customers' business processes by offering a wide range of products and economic solutions.
