22.BS.0153 4-circuit protection valve
Technical Specifications
| Port 1 | M22x1,5 |
| Port 12 | M16x1,5 |
| Port 21 | M16x1,5 |
| Port 22 | M16x1,5 |
| Port 11 | M16x1,5 |
| Port 23 | M16x1,5 |
| Port 24 | M16x1,5 |
| Pressure | MAX 10 BAR |
| Opening Pressure 21 | 6,9 BAR |
| Opening Pressure 22 | 6,9 BAR |
| Opening Pressure 23 | 7 BAR |
| Opening Pressure 24 | 7,5 BAR |
| Closing Pressure 21 | 4,5 BAR |
| Closing Pressure 22 | 4,5 BAR |
| Closing Pressure 23 | 4,5 BAR |
| Closing Pressure 24 | 6 BAR |
Vehicles Used In
| Marka | Model | Motor |
|---|---|---|
| KNORR-BREMSE |
Diğer Oemler
Economic and quality solutions from MPT Main Part with 22.BS.0153 for KNORR-BREMSE (AE4448) vehicles in 4-circuit protection valve products! With our global sales network, customer-focused service policy, and large stock capacity, we maximize the efficiency of your vehicles.
