22.BS.0175 4-circuit protection valve

22.BS.0175 | 4-circuit protection valve
22.BS.0175 | 4-circuit protection valve
1) AE4408, 22.BS.0175 4-circuit protection valve, MPT Main Part
2) AE4408, 22.BS.0175 4-circuit protection valve, MPT Main Part

22.BS.0175

4-circuit protection valve

EAN Code : 8683443078595
KNORR-BREMSE
AE 4408

Technical Specifications

Port 1 M22x1,5
Port 21 M16x1,5
Port 22 M16x1,5
Port 23 M16x1,5
Port 24 M16x1,5
Opening Pressure 21 7 BAR
Opening Pressure 22 7 BAR
Opening Pressure 23 5,7 BAR
Opening Pressure 24 5,7 BAR
Closing Pressure 21 4,7 BAR
Closing Pressure 22 4,7 BAR
Closing Pressure 23 4,7 BAR
Closing Pressure 24 4,7 BAR

Vehicles Used In

Marka Model Motor
KNORR-BREMSE

Diğer Oemler

KNORR-BREMSE AE 4408
KNORR-BREMSE AE4408
AE 4408 AE 4408 4-circuit protection valve
Quality and economic 4-circuit protection valve (22.BS.0175) for your KNORR-BREMSE (AE4408) vehicles is now very close with MPT Main Part! With our wide product range in the commercial vehicle sector, we reduce operating costs and increase efficiency for businesses. Increase your profitability.
