23.BS.0097 4-circuit protection valve

23.BS.0097 | 4-circuit protection valve
23.BS.0097 | 4-circuit protection valve
1) 9347144030,235500350,59480Y43G6, 23.BS.0097 4-circuit protection valve, MPT Main Part
2) 9347144030,235500350,59480Y43G6, 23.BS.0097 4-circuit protection valve, MPT Main Part

23.BS.0097

4-circuit protection valve

EAN Code : 8683443088396
WABCO
934 714 403 0
KING LONG
235500350
JAC
59480-Y43G6

Products Used In

23.BS.0108 - 4-circuit protection valve, Repair Kit
23.BS.0108

4-circuit protection valve, Repair Kit

Technical Specifications

Port 1 M22x1,5 Voss
Opening Pressure 21 6,9 BAR
Opening Pressure 22 6,9 BAR
Closing Pressure 21 6,4 BAR
Closing Pressure 22 6,4 BAR
Closing Pressure 23 6,4 BAR
Closing Pressure 24 6,4 BAR
Opening Pressure 23 7 BAR
Opening Pressure 24 6,9 BAR
Port 21 M22x1,5 Voss
Port 22 M22x1,5 Voss
Port 23 M22x1,5 Voss
Port 24 M22x1,5 Voss

Vehicles Used In

Marka Model Motor
FOTON
JAC
KING LONG
SUNWIN
WABCO

Diğer Oemler

JAC 59480-Y43G6
KING LONG 235500350
WABCO 934 714 403 0
WABCO 9347144030
934 714 403 0 235500350 59480-Y43G6 59480-Y43G6 4-circuit protection valve 235500350 4-circuit protection valve 934 714 403 0 4-circuit protection valve
The ideal solution for WABCO (9347144030), KING LONG (235500350), JAC (59480Y43G6) in the 4-circuit protection valve category: 23.BS.0097 awaits you at MPT Main Part! With our superior service approach in the global market, economic price policy, and fast delivery advantage, we make a difference in the commercial vehicle sector.
