23.BS.0099 4-circuit protection valve

23.BS.0099 | 4-circuit protection valve
23.BS.0099 | 4-circuit protection valve
1) 9347140110,ACHA001, 23.BS.0099 4-circuit protection valve, MPT Main Part
2) 9347140110,ACHA001, 23.BS.0099 4-circuit protection valve, MPT Main Part

23.BS.0099

4-circuit protection valve

EAN Code : 8683443088419
WABCO
934 714 011 0
DAF
ACHA001

Products Used In

23.BS.0109 - 4-circuit protection valve, Repair Kit
23.BS.0109

4-circuit protection valve, Repair Kit

Technical Specifications

Port 1 M22x1,5
Port 21 M16x1,5
Port 22 M16x1,5
Port 23 M16x1,5
Port 24 M16x1,5
Opening Pressure 21 7,2 BAR
Opening Pressure 22 7,2 BAR
Opening Pressure 23 7,7 BAR
Opening Pressure 24 7,3 BAR
Closing Pressure 21 4,8 BAR
Closing Pressure 22 4,8 BAR
Closing Pressure 23 4,8 BAR
Closing Pressure 24 5,5 BAR

Vehicles Used In

Marka Model Motor
DAF
LEYLAND
PACCAR
WABCO

Diğer Oemler

DAF ACHA001
WABCO 934 714 011 0
WABCO 9347140110
934 714 011 0 ACHA001 ACHA001 4-circuit protection valve 934 714 011 0 4-circuit protection valve
Discover the privileges offered by MPT Main Part with 4-circuit protection valve - 23.BS.0099, specially produced for your WABCO (9347140110), DAF (ACHA001) brand vehicles! MPT Main Part, holding a leading position in global trade, stands out in the sector with its focus on customer needs, wide product game, and competitive prices. Through our high-quality products and powerful global distribution network, we provide the most reliable service to enhance the performance and durability of your vehicles.
